3dB Fixed Attenuator, SMA Male to SMA Female, 5Watts, DC-26.5GHz, VSWR<1.3

ZOMWAVE coaxial 50 Ohm attenuator is manufactured to precise RF/microwave industry specifications. ATT05W03-26-MAJ-MAP-99 is SMA rf fixed attenuator operating DC to 26.5 GHz and rated for 5 Watts.Available from 3 to 30 dB.RoHS Compliant.ISO Certified. Shipped in 10days with small quantities.

12in

P/N:ATT05W03-26-MAJ-MAP-99 Quantity Unit Price 01~09 US$68.44 10~49 US$65.70 50~99 US$62.96 100~199 US$58.86 200+ Call Us

ORDER NOW

*More quantity request or best price, please sent the RFQ to zomwave sales

Pictures

Specifications

Q1. What is your delivery time?

A1). We promise within 5 days ship out for the standard products less than 200 pcs.

A2). Customized products would be 2~3 weeks lead time.

Q2. Which shipping way is available and how to track?

A1). By international Express like FedEx, DHL, TNT, UPS, normally door to door in 5~7 days.

A2). Tracking No. will be sent after goods ship out.

Q3. Do your price include freight cost and custom duty?

A1). Price do NOT include the freight cost and import duty.

A2). We can quote you the detail freight cost by our forwarder agent.

Q4. Which payment way is workable?

A1). We accept Wire Transfer (T/T) and PayPal payments (order value less than USD$500).

A2). Payment in advance for new clients.

Q5. What is the MOQ of your products?

A1). No MOQ request for standard products (include customized length cable) on our website.

A2). Other customized products we request 500 pcs MOQ (Minimum Order Quantity).

Q6. Could you supply the sample for me to test first?

A1). We are honored to offer you samples. New clients are expected to pay the sample fee.

A2). Sample fee can be refunded in your mass production order (total quantity up to 1000 pcs).

Configuration
Connector Series 1	SMA
Connector Gender 1	Male
Connector Series 2	SMA
Connector Gender 2	Female
Body Materials and Plating	Stainless Steel with Passivated
Heat Sink	Black anodized aluminum
Direction	Bidirectional
Electric Specifications
Impedance	50ohm
Frequency Range(From DC)	26.5GHz
VSWR	≤1.3:1 (DC 0~26.5GHz)
Attenuation	3dB
Attenuation Accuracy	±0.6dB
Input Power, CW	5W@25°C
Mechanical Characteristics
Mating Cycles	≥ 500 cycles
Mating Torque	5~7 in - lbs
Net Weight	10g
Environmental Characteristics （RoHS Complliant)
Temperature Rating	-55°C ~ +125°C
Corrosion (Salt Spray)	MIL-STD-202, Method 101, Condition B
Vibration	MIL-STD-202, Method 204, Condition D, 20 Gs
Shock	MIL-STD-202, Method 213, Condition I, 100 Gs
Thermal Shock	MIL-STD-202, Method 107. Cond. B, -40°C to +85°C
Moisture Resistance	MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude)	MIL-STD-202, Method 105, Condition C, 70k Ft.
