IPEX(UFL) Cable Assembly

U.FL Plug Right Angle to U.FL Plug Right Angle, RG1.13 Cable, 6GHz

No MOQ, 5 days Shipping out, 100% fully tested to ensure high quality. U.FL Plug Right Angle to U.FL Plug Right Angle, RG1.13 Cable. ZOMWAVE RG178 flexible coax cable is 50 Ohm and has a PTFE dielectric. Our RG1.13 coax is constructed with a 0.072 jacket made of FEP, assemblies are part of over 40,000 RF, microwave and millimeter wave components. ZOMWAVE coaxial cable assembly products are suitable for automobiles, broadband, industry 4.0, instrumentation, medical treatment, military, quantum computing, smart agriculture, 5G wireless, etc. The U.FL Plug Right Angle to U.FL Plug Right Angle, RG1.13 Cable assembly is composed of Flexible RG1.13 Cable. RG1.13 coax has a shield count of 1. The Flexible RG1.13 Cable. are perfect for interconnection of coaxial components or sub-systems connection. The cable construction includes a silver-plated copper-clad steel center conductor, low loss PTFE, and tin overcoated copper shield braiding, which minimizes signal leakage. Connectors have brass, nickel plated coupling nut over a gold plated connector body that make the connection more reliable. The Flexible RG1.13 Cables are available in variety of length to meet your requirements. Variations of IPEX(UFL) cable assemblies can also be manufactured and will be shipped within 5 days.

Standard Lengths :

12in 24in 36in 48in

P/N:U1PRU1PR-M113-12IN-01 Quantity Unit Price 01~09 US$2.06 10~49 US$1.99 50~99 US$1.91 100~200 US$1.78 200+ Call Us
P/N:U1PRU1PR-M113-24IN-01 Quantity Unit Price 01~09 US$2.36 10~49 US$2.27 50~99 US$2.19 100~200 US$2.03 200+ Call Us
P/N:U1PRU1PR-M113-36IN-01 Quantity Unit Price 01~09 US$2.65 10~49 US$2.55 50~99 US$2.46 100~200 US$2.29 200+ Call Us
P/N:U1PRU1PR-M113-48IN-01 Quantity Unit Price 01~09 US$2.95 10~49 US$2.84 50~99 US$2.73 100~200 US$2.54 200+ Call Us

*More quantity request or best price, please sent the RFQ to zomwave sales



ufl cables, ufl plug cables, ufl cable assemblies, ipex cables

ufl cables, ufl plug cables, ufl cable assemblies, ipex rf cables

Q1. What is your delivery time?

A1). We promise within 5 days ship out for the standard products less than 200 pcs.

A2). Customized products would be 2~3 weeks lead time.

Q2. Which shipping way is available and how to track?

A1). By international Express like FedEx, DHL, TNT, UPS, normally door to door in 5~7 days.

A2). Tracking No. will be sent after goods ship out.

Q3. Do your price include freight cost and custom duty?

A1). Price do NOT include the freight cost and import duty.

A2). We can quote you the detail freight cost by our forwarder agent.

Q4. Which payment way is workable?

A1). We accept Wire Transfer (T/T) and PayPal payments (order value less than USD$500).

A2). Payment in advance for new clients.

Q5. What is the MOQ of your products?

A1). No MOQ request for standard products (include customized length cable) on our website.

A2). Other customized products we request 500 pcs MOQ (Minimum Order Quantity).

Q6. Could you supply the sample for me to test first?

A1). We are honored to offer you samples. New clients are expected to pay the sample fee.

A2). Sample fee can be refunded in your mass production order (total quantity up to 1000 pcs).


Connector Series 1 U.FL
Connector Gender 1 Plug
Connector Angle 1 Right Angle
Connector Mount Method1 None
Body Materials and Plating 1 Copper Alloy, Gold Plated
Connector Series 2 U.FL
Connector Gender 2 Plug
Connector Angle 2 Right Angle
Connector Mount Method 2 None
Body Materials and Plating 2 Copper Alloy, Gold Plated
Cable Type  RG1.13
Electric Specifications
Impedance 50ohm
Frequency Range(From DC) 6GHz
VSWR ≤1.50:1 (DC 0~6GHz)
Insertion Loss Depends on cable length
Voltage Rating 335 V(rms)
Dielectric Withstanding Voltage 500 V
Insulation Resistance ≥500 Mohm
Mechanical Characteristics
Mating Cycles ≥ 30 cycles
Mating Torque 30 in - lbs
Environmental Characteristics (RoHS Complliant)
Temperature Rating -40°C ~ +85°C
Corrosion (Salt Spray) MIL-STD-202, Method 101, Condition B
Vibration MIL-STD-202, Method 204, Condition D, 20 Gs
Shock MIL-STD-202, Method 213, Condition I, 100 Gs
Thermal Shock MIL-STD-202, Method 107. Cond. B, -40°C to +85°C
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
Cable Specification
Center Conductor Silver plated copper
Dielectric FEP
Jacket FEP
Jacket Diameter(mm) 1.13±0.05
Min. Bending Radius(mm) 4
Shielding Effect(dB) >70
Weight(kg/km) 2 (Reference)
Coaxial Cable Attenuation @ 20℃ and Sea Level, Power
Frequency (GHz) Attenuation(dB/m)
1 2.20
2 3.10
3 3.80
4 4.40
5 4.90
6 5.4
