SMC Connector

SMC Male Right Angle Thru Hole PCB Connector, .200 inch x .051 inch Hole, 6GHz

5 Days Ship Out. Negotiated Prcie. ZOMWAVE SMC Male Right Angle Thru Hole PCB Connector, .200 inch x .051 inch Hole connector has an interface type of thru hole and a 50 Ohm impedance. SMC male connector uses shield/contact solder as an attachment method. Our male SMC pcb connector provides a minimum frequency of DC and a maximum frequency of 6GHz. ZOMWAVE SMC male pcb connector has a PTFE dielectric type and a VSWR of 1.25. ZOMWAVE SMC Male Right Angle Thru Hole PCB Connector, .200 inch x .051 inch Hole connector has a brass body with gold plating. Our SMC connector uses beryllium copper contact. This SMC male pcb RF connector is RoHS and REACH compliant. Our SMC male connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment.

12in

P/N:MCPR-NMSS-PTHT-99 Quantity Unit Price 01~09 US$6.00 10~49 US$7.14 50~99 US$5.56 100~499 US$5.17 500+ Call Us
ORDER NOW

*More quantity request or best price, please sent the RFQ to zomwave sales

Pictures
Specifications



smc connector, smc male connector, smc male right angle

smc connector, smc male connector, smc male right angle

smc connector, smc male connector, smc male cable

smc connector, smc male connector, smc cable assembly

Q1. What is your delivery time?

A1). We promise within 5 days ship out for the standard products less than 200 pcs.

A2). Customized products would be 2~3 weeks lead time.

Q2. Which shipping way is available and how to track?

A1). By international Express like FedEx, DHL, TNT, UPS, normally door to door in 5~7 days.

A2). Tracking No. will be sent after goods ship out.

Q3. Do your price include freight cost and custom duty?

A1). Price do NOT include the freight cost and import duty.

A2). We can quote you the detail freight cost by our forwarder agent.

Q4. Which payment way is workable?

A1). We accept Wire Transfer (T/T) and PayPal payments (order value less than USD$500).

A2). Payment in advance for new clients.

Q5. What is the MOQ of your products?

A1). No MOQ request for standard products (include customized length cable) on our website.

A2). Other customized products we request 500 pcs MOQ (Minimum Order Quantity).

Q6. Could you supply the sample for me to test first?

A1). We are honored to offer you samples. New clients are expected to pay the sample fee.

A2). Sample fee can be refunded in your mass production order (total quantity up to 1000 pcs).

smc connector, smc male connector, smc right angle connector

Configuration
Connector Series  SMC
Connector Gender  Male
Connector Angle Right Angle
Connector Mount Method None
Attachment Method Solder
Interface Type Thru Hole
Material
Centre Contact Phosphorus-copper gold plated
Body Brass, gold plated
Insulators PTFE
Electrical Specifications
Impedance 50 ohm
Frequency Range(From DC) 6GHZ
VSWR ≤1.25:1 (DC 0~6GHz)
Insertion Loss 0.05 xSqt.(f_Ghz)
Voltage Rating 150 V(rms)
Dielectric Withstanding Voltage 500 V
Insulation Resistance ≥500 Mohm
Mechanical Characteristics
Mating Cycles ≥ 500 cycles
Mating Torque 5-7 in - lbs
Environmental Characteristics (RoHS Complliant)
Temperature Rating -45°C ~ +125°C
Corrosion (Salt Spray) MIL-STD-202, Method 101, Condition B
Vibration MIL-STD-202, Method 204, Condition D, 20 Gs
Shock MIL-STD-202, Method 213, Condition I, 100 Gs
Thermal Shock MIL-STD-202, Method 107. Cond. B, -40°C to +85°C
Moisture Resistance MIL-STD-202, Method 106, Less Step 7B
Barometric Pressure (Altitude) MIL-STD-202, Method 105, Condition C, 70k Ft.
